18 Ergebnisse gefunden
LTA-LSA
Lüftertaster mit Drehknopf für AUF / ZU
… 118476) Gefahr durch elektrischen Strom! Beim Betrieb elektrischer Geräte stehen zwangsläufig bestimmte Teile unter gefährlicher Spannung. Unsachgemäßer Umgang mit diesen Geräten kann deshalb zu Tod oder schweren Körperverletzungen sowie zu erheblichen Sachschäden führen. Sicherheitshinweise XX Anschluss nur durch Elektrofachkraft durchführen. XX Vor der Installation muss dieses Beiblatt unbedingt gelesen werden. XX Einschlägige Normen und Vorschriften beachten, insbesondere DIN VDE 0100-600 oder die länderspezifischen Vorschriften beachten. XX Als netzseitige Trennvorrichtung einen bauseitigen 2-poligen Leistungsschutzschalter (Überspannungskat. III) mit Verrieglungsmöglichkeit verwenden. XX Nach dem Einbau muss der gesamte Klemmenbereich abgedeckt sein. Nur so ist das Gerät ausreichend gegen unzulässiges Berühren spannungsführender Teile geschützt. 230V AC L1i L2h N 230 V AC 24V A 24V B Signal LIN 230V AC GND +24V L1-N +24V GND L2-N DANGER! Danger of electric shock! Before working on the electrical system interrupt the power supply, secure it against being switched on again and verify the safe isolation from supply. Wiring diagram Notes on electrical connection: XX The cabling must be carried out in such a way that there is sufficient clearance (> 20 mm) between input and output line and the power line and output line are laid separately XX Always use wire-end ferrules for wire cores XX Insulate wires that are not used XX Wiring diagram of the 24V window drives has to be considered. At 24 V DC and with long supply cable, the cable must have a sufficiently large cross-section to prevent voltage drop. Calculate cross-section! Connection terminals 24 V DC, 2,5 A ∓ ± EN Wiring diagram NT 2,5 A-24 V SM DIR EN Power supply NT 2,5 A-24 V SM DIR 230V AC 195297-01 NT 2,5 A-24 V SM DIR power supply Technical data ID 195293 Mains voltage 220 - 240 V AC +/-10% Mains frequency 50-60 Hz Input current 0,58 A Idling input power 0,24 W Output power 60 W Output voltage 24 V DC ±5% (SELV) Output current 2,5 A, ED 30%, … 95% max. installation height a.s.l. 2000 m IP rating IP 20 Protection rating II Standard EN60335-1 Application area dry rooms Connection cross-section 1,5 mm² Dimensions (LxWxH) 200 x 50 x 25 mm Group control max. 10 power supplies can be connected in parallel (230 V) Max. cable length switch ↔ power supply (230V) 50 m Application The NT 2,5 A-24 V SM DIR power supply is a controlled power supply designed for use in the one-phase AC network. It has an integrated direction control for the operation of 24 V window drives. The running direction of the drives is determined by the polarity of the supply voltage. It serves as a power supply for GEZE 24 V window drives. Perfect and safe device operation requires adequate transport, proper storage, assembly and installation. DANGER! LTA-LSA (ID: 118476) Danger of electric shock! During the operation of electrical devices, certain parts are always energised with hazardous voltage. Improper use of these devices can thus lead to death or serious physical injuries as well as to considerable property damage. Safety instructions XX Always have the connection set up by a qualified electrician. XX This supplementary sheet must always be read before installation. XX Heed the relevant standards and regulations, in particular DIN VDE 0100-600 or country-specific regulations. XX As a line-side disconnecting device, use an on site 2-pole circuit breaker (overvoltage cat. III) with locking possibility. XX The entire connector area must be covered after installation. This is the only way to protect the device sufficiently against impermissible contact with live parts. XX Before the system is released for operation, an insulation measurement of the system's line network must be performed and logged. 230V AC 24V A 24V B Signal LIN 230V AC GND +24V L1-N +24V GND L2-N L1i L2h N 230 V AC
… 118476). Bei Kindern oder Personen mit eingeschränktem Urteilsvermögen muss ein Schlüsselschalter mit Aus-Voreinstellung verwendet werden (z.B. GEZE Mat.Nr. 117996 für SCT, 090176 für Zylinder). Die Schalter müssen so angebracht sein, dass die Gefahrenstellen eingesehen werden können. DE … m are to be considered and carried out. One measure, for example, is the use of switch with OFF default setting (e.g. GEZE vent switch LTA-LSA Mat. No. 118476). In the case of children or persons with a limited ability to judge, a key-operated switch with an OFF default setting must be used (e.g. GEZE Mat. No. 117996 for SCT, 090176 for cylinder). The switch has to be mounted so that the points of danger can be seen. XX After the installation has been completed, check that the system is set correctly and is functioning correctly and safely. XX Check all the functions by means of a trial run. àà The end user has to be instructed in all the important operating and handling steps after completion. GB … x 1,5 mm2 LTA-LSA (ID: 118476)
… 118476 Netzteile / Power supplies NT 1,1A-24 V UP NT 1,5A-24 V HS NT 2,5A-24 V HS NT 4,2A-24 V HS ID 151426 ID 151425 ID 151424 ID 151423 Gehäuse / Housing GEZE Aufputz-Gehäuse / GEZE surface-mounted housing 193 x 130 x 82 mm ID 152010 Testbetrieb / Test operation Nach Anschluss der Antriebe und der 24V-Versorgungsspannung kann mit Hilfe der Taste “Fenster AUF” (9) und der Taste „Fenster ZU“ (8) ein Probelauf der Antriebe durchgeführt werden, auch wenn das KNX-System noch nicht programmiert ist. Following connection of the drives and the 24V supply voltage, the key “Window OPEN” (9) and the key “Window CLOSED” (8) can be use to carry out a test run, even if the KNX system has not been programmed at this point. GEZE GmbH Reinhold-Vöster-Strasse 21–29 71229 Leonberg Germany Tel.: 0049 7152 203-0 Fax: 0049 7152 203-310 www.geze.com
